Description

Vertical set double socket outlet surface-mounted hermetic IP65 grey with flap 2x[2P+Z] + staircase switch IP65 Aquant 2K

Set consisting of a double vertical surface-mounted socket AQUANT™ 2K IP65 and staircase switch IP65 provides reliable power supply in demanding conditions, thanks to a hermetic water, dust and UV radiation-resistant construction.

The use of innovative two-component sealing technology (2K) and integrated rubber cable glands (in IP65 version) guarantees high durability, tightness and protection even in industrial environments, garages or laundries.

Solid housing construction and convenient installation make the product perfectly combine functionality with modern design.

Key features:

• Sockets 16A/250V – threaded terminals
• Socket 2x2P+Z with contact shutter
• Housing color: grey RAL 7035
• Dimensions: 230x81x58mm
• Single hermetic socket with earthing
• Hermetic IP65 (for outdoor applications)
• Solid housing construction
• Socket sets x2 and x3 in one housing
• Increased UV resistance
• Manufactured in 2K technology (guaranteed sealing)
• Durable mechanism with proven design
• Possibility of installation in vertical sets
• Additional protection integrated with the base in the form of movable rubber cable glands.
• Reliable mechanism of sockets and switches
• Application in garage halls, laundries, warehouses, catering facilities
• Standard: PN-EN-60669-1:2006, PN-IEC-60884-1:2006

AQUANT™ 2K – New series of hermetic surface-mounted electrical accessories

New AQUANT™ 2K series has been developed with demanding industrial applications in mind and wherever the reliability of electrical installations is key.

Thanks to the use of innovative two-component sealing 2K and halogen-free flat cable gland, it provides exceptional tightness and resistance to water, dust and changing atmospheric conditions.

Additionally, elegant design in trendy colors means that AQUANT™ products fit current design trends, combining functionality with aesthetics.

Key features of AQUANT™ 2K series

• Impact resistance IK07 – solid construction ensures durability in environments with high risk of mechanical damage.
• Protection against dust and water at IP55 level – possibility to extend protection to IP65 through the use of optional cable gland.
• Durable materials – construction made of durable ABS+TPE plastic, resistant to UV radiation, which guarantees longevity in harsh atmospheric conditions.
• Easy installation and configuration – possibility to assemble sockets and switches in horizontal and vertical combinations. Double, triple sets and combinations of sockets with switches are available.
• 16A sockets and 10AX switches – reliable and durable, available in various configurations (French sockets and Schuko).
• Tested in extreme conditions – ideal for use in industry, agro-food plants, laundries, garages and other demanding environments.

Application of AQUANT™ 2K series:

AQUANT™ series is ideal for places requiring increased protection against moisture, dust and UV radiation. It will work perfectly in:

• garage halls, car washes, industrial and logistics plants,
• places exposed to extreme atmospheric conditions,
• basements, laundries, as well as in home installations.

IP65 tightness (EN60529)

The IP system indicates the degree of protection provided by enclosures against access to dangerous parts, ingress of foreign solid objects, ingress of water and a system for providing additional information related to such protection.

The presented product has the following properties:

• protection against access to dangerous parts with wire
• dust-tight protection
• protection against water jet (12.5 l/min) poured onto the housing from any side

About the manufacturer:

ELEKTRO-PLAST Nasielsk is one of the leading manufacturers of electrical installation accessories, whose products, such as hermetic AQUANT™ series, are known for quality and reliability both in Poland and on foreign markets of Eastern Europe and the European Union.

Thanks to almost 40 years of experience, the company has become a symbol of innovation and thoughtful design, constantly developing and expanding its offer in accordance with the highest quality standards confirmed by ISO 9001:2008 standard.

Products of ELEKTRO-PLAST Nasielsk are distinguished by durability, advanced technology and flexibility of applications, perfectly meeting the needs of the modern installation market.
